SD90-C5 Crawler Dozer

Overall Weight

106,260 Kg


Engine Model

Cummins QST30


Engine Power

708kW(950hp) @ 2100rpmf


Overview of the SD90 Dozer

The Shantui SD90 Dozer is a high-performance machine designed for heavy-duty earthmoving tasks in challenging environments. Powered by the Cummins QST30 engine, the SD90 delivers 708 kW (950 hp) at 2100 rpm and a maximum torque of 4191 Nm. This robust dozer is equipped with a torque converter and planetary gear transmission, ensuring efficient power delivery for the toughest jobs. With a wide track gauge and superior blade capacity, the SD90 offers unmatched stability and ground penetration, making it ideal for mining, construction, and large-scale earthmoving applications.

A bulldozer, yellow, grading soil on a construction site

Key Features:

  • Powerful Engine: The Cummins QST30 engine provides 950 hp (708 kW) of gross power and 4191 Nm of torque, ensuring high productivity in demanding applications.
  • Heavy-duty Blade: Equipped with a semi-U blade that has a capacity of 39 m³, the SD90 excels in earthmoving tasks.
  • Superior Traction: The machine features a large track grounding area, ensuring enhanced stability and reduced ground pressure.
  • Advanced Transmission System: The Torqflow transmission, with a 3-element torque converter and hydraulically actuated gear shift, delivers smooth performance and efficiency.
Yellow bulldozer pushing a pile of dirt and rocks on a sunny day — Shantui QLD in Kingsthorpe, QLD

Technical Specifications:

  • Engine: Cummins QST30, 708 kW (950 hp) gross power @ 2100 rpm
  • Displacement: 30.5 L
  • Max Torque: 4191 Nm @ 1300 rpm
  • Traveling Speed: Forward: 0–3.5 km/h, 0–6.3 km/h, 0–10.9 km/h // Reverse: 0–4.7 km/h, 0–8.4 km/h, 0–14.3 km/h
  • Operating Weight: 106,260 kg
  • Ground Pressure: 143.7 kPa
  • Fuel Capacity: 1638 L
  • Max Lifting Height of Blade: 1620 mm
  • Max Digging Depth of Blade: 1010 mm
  • Blade Capacity: 39 m³
  • Blade Type: Semi-U heavy duty
  • Ripper: Single shank ripper, 5843 kg, Max. Ripping Depth: 1672 mm

Why Choose the Shantui SD90 Dozer?

The SD90 Dozer is built for maximum efficiency in heavy-duty applications such as mining, large-scale construction, and earthmoving. With its powerful engine, advanced transmission system, and superior blade capacity, it can handle the most demanding tasks with ease. The SD90 is designed for operators seeking durability, performance, and high productivity.
