DH17-B3 Crawler Dozer

Overall Weight

17,500 kg


Engine Model

Weichai WD10G190E214


Engine Power

140 kW (188 hp) @ 1900 rpm


Overview of the Shantui SD17 Dozer

The Shantui SD17 Dozer is a versatile and powerful machine designed for demanding applications in construction, earthmoving, and site preparation. Equipped with the Weichai WD10G190E214 engine, it delivers 140 kW (188 hp) at 1900 rpm, ensuring reliable performance in tough job site conditions. Featuring an advanced electric control planetary gear transmission and torqflow drive system, the SD17 provides smooth operation, high efficiency, and exceptional durability. Its Straight-Tilt blade, three-shank ripper, and heavy-duty undercarriage make it an excellent choice for a wide range of earthmoving tasks.

A bulldozer, yellow, grading soil on a construction site

Key Features:

  • Powerful Engine: The Weichai WD10G190E214 engine delivers 140 kW (188 hp) with a mechanical fan cooling system for maximum efficiency.
  • Advanced Transmission: 3-speed forward and 3-speed reverse torqflow transmission, hydraulically actuated for smooth and precise operation.
  • Heavy-Duty Blade: The Straight-Tilt blade has a capacity of 4.5 m³ (XL) / 3.8 m³ (LGP), ideal for pushing and leveling material.
  • High-Capacity Ripper: Equipped with a three-shank ripper for superior penetration, with a maximum ripping depth of 572 mm.
  • Strong Chassis & Undercarriage: A suspended equalizer bar design with track shoe options up to 1100 mm for enhanced stability and traction.
Yellow bulldozer pushing a pile of dirt and rocks on a sunny day — Shantui QLD in Kingsthorpe, QLD

Technical Specifications:

  • Engine: Weichai WD10G190E214, 140 kW (188 hp) @ 1900 rpm
  • Transmission: Electric control planetary gear, 3 forward / 3 reverse gears
  • Blade Capacity: 4.5 m³ (XL) / 3.8 m³ (LGP) Straight-Tilt blade
  • Ripper: Three-shank, max depth 572 mm
  • Fuel Capacity: 338 L
  • Operating Weight: 17,500 kg (XL) / 19,200 kg (LGP)
  • Track Gauge: 1880 mm (XL) / 2430 mm (LGP)
  • Max Blade Lifting Height: 1010 mm (XL) / 1005 mm (LGP)
  • Max Digging Depth: 540 mm (XL) / 485 mm (LGP)

Why Choose the Shantui SD17 Dozer?

The SD17 is built for efficiency, durability, and power, making it the ideal bulldozer for earthmoving, construction, and infrastructure development. With a high-torque Weichai engine, advanced torqflow transmission, and a rugged blade and ripper system, it delivers exceptional performance in challenging conditions. Whether you’re grading, excavating, or preparing a site, the SD17 is a cost-effective, high-performing solution for demanding projects.
